Description

The Vaunt Essentials Compact Green Crossline Laser is the perfect product to make those essential, but mundane jobs both around the home and onsite quick and easy. From putting up shelves, pictures, mirrors, curtain rails, kitchen cabinets to wallpaper and tiles, the laser generates an accurate horizontal and vertical line for accuracy and pinpoint precision.
The wall mount brackets included, allows you to attach the laser directly to any metal surfaces or using the 3 pin holes, it can be hooked on objects or simply hung on a nail.
The laser requires 2 AA alkaline batteries (not included).

Features:

• High-visibility green cross-line (H + V) for precise layouts


• Self-levelling within ±4° with pendulum-lock for safe transport or angled projection


• Ultra-compact (75 × 80 × 70 mm) and lightweight (0.18 kg) in a shock-resistant EVA housing


• Foldable wall bracket with ¼”?5/8″ tripod adaptor and three pin-hole mounting options

Specification:

• Beam type: Green cross-line (1 horizontal + 1 vertical)


• Wavelength / Class: 515–532 nm / Class 2


• Accuracy: ±2 mm @ 5 m


• Working range: Up to 7.5 m (line mode)


• Power: 2×AA alkaline batteries (not included), up to 12 h runtime


• Operating temp.: 0 °C to +40 °C

Kit includes:

• Vaunt E1503000 laser unit


• Foldable wall bracket (¼”?5/8″ tripod adaptor)


• EVA canvas carry bag


• Quick-start guide
